VR420AA1003-0000

VR420AA1003-0000

Honeywell
$430.20

VR420AA1003-0000 -- Honeywell -- COMB GAS VALVE 3/4 220/240V

Product Description

  • Estimated Lead Time: 6-8 Weeks
  • Manufacturer: Honeywell
  • COMB GAS VALVE 3/4 220/240V
  • Honeywell 3/4" Solenoid Valve
  • Honeywell VR420AA1003-0000 Solenoid Valve 3/4" Double Class 230V, 3-37mbar Regulator
  • Capacity (cfh), 0.64 sp. gr. gas @ 1 in. w.c. P: 300
  • 32W 150mA
  • The VR415/VR420/VR425 Class A Double Block Valves Are Used For Control Of Gaseous Fuels In Gas-Fired Power Burners, Atmospheric Gas Boilers, Ovens, Furnaces, Incinerators, Roof-Top Units, Makeup Air Units And Other Gas Consuming Appliances.
  • Class A Double Block For Control Of Gaseous Fuels In Gas Consuming Appliances In Accordance With International Standards.
  • Main Body With Two Single-Seat Shutoff Valves.
  • Provides For Mounting Optional Flanged Pressure Switches.
  • Closing Time: < 1 Second.
  • Coils Suitable For Permanent Energization.
  • Fine Mesh Screen (Strainer) Between Inlet Flange And Main Body.
  • Various Pressure Tap Points At Main Body Available, When No Additional Valves Or Pressure Switches Are Used.
  • Plug Connector According To DIN 43650.
  • CSA Rated For 1/2 Psi (34.5 mBar).
  • Maximum Operating Pressure 2.9 Psi (200 mBar).
  • Shipping Weight: 2 Kg
