STA72L-E3G000-1-A-HH0-11S-A-00A0-F1-0000

Estimated Lead Time : In stock. Usually ships in 3-5 Working days.

Manufacturer : Honeywell

Absolute In-Line : STA72LURL/Max Span : 500 (35)LRL : 0 (0)Min Span : 5 (.35)Units : psia (barA)

TABLE IProcess Head & Diaphragm Materials

E- Process Head/Reference Head Mat'l1b: 316 Stainless Steel /316 Stainless Steel

Barrier Diaphragm Material : 316L SS

3-Fill Fluid : Silicone Oil 704

G-Process Connection :Size/Type : 1/2" NPT (female)Material : Same as Process Head 1a

0-Bolt/Nuts Materials : None

0-Vent/Drain Type/LocationHead Type : NoneVent Type : NoneVent Location : NoneVent Material : None

0-Gasket Materials : None

TABLE II1- Meter Body & Connection OrientationHead/Connect Orientation : Standard, High Side Left, Low Side Right2 / Std Head Orientation

TABLE IIIA-AGENCY APPROVALS : <FM> Explosion proof, Intrinsically Safe, Non-incendive, & Dustproof

TABLE IVH- Electronic Housing Material & Connection TypeMaterial : 316 Stainless Steel (Grade CF8M)Connection : M20Lightning Protection : Yes

H- Output/ProtocolAnalog Output : 4-20mA dcDigital Protocol : HART Protocol

0-Customer Interface SelectionsIndicator : NoneExt Zero, Span & Config Buttons : NoneLanguages : None

TABLE V1-App S/W : Diagnostics-Standard Diagnostics1- Output Limit,Failsafe & Write Protect SettingsWrite Protect : DisabledFail Mode : High> 21.0mAdcHigh & Low Output Limits : Honeywell Std (3.8 - 20.8 mAdc)

S-General Configuration : Factory Standard

TABLE VIA- Accuracy and CalibrationAccuracy : StandardCalibrated Range : Factory StdCalibration Qty : Single Calibration

TABLE VIIMounting Bracke0 - Bracket Type : NoneMaterial : None

0 - No customer tagA0-No Conduit Plugs or Adapters Required

TABLE 8 OTHER Certifications & Options: (String in sequence comma delimited (XX, XX, XX...)F1- Certifications & Warranty : alibration Test Report & Certificate of Conformance (F3399)

TABLE 9-Manufacturing Specials0000-Factory Identification

Net Weight STA700: 8.3 pounds (3.8 Kg). STA70L: 3.6 pounds (1.6 Kg) with Aluminum Housing

Shipping Weight : 4 Kg
