1SDA068343R0001

1SDA068343R0001

ABB
$633.60

1SDA068343R0001 -- ABB --XT4H 250 TMA R200 3P F F

Product Description

  • \nManufacturer : ABB\n\n
  • \nExtended Product Type : XT4H 250 TMA R200 3P F F\n\n
  • \nProduct ID : 1SDA068343R0001\n\n
  • \nEAN : 8015644022518\n\n
  • \nCatalog Description:XT4H 250 TMA R200 3P F F\n\n
  • \nLong Description:C.BREAKER TMAX XT4H 250 FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 250 I3=1250...2500 A\n\n
  • \nXT4H 250 TMA 250-2500 3p F F - image 0\n\n
  • \nEAN : 8015644022518\n\n
  • \nMinimum Order Quantity:1 piece\n\n
  • \nCustoms Tariff Number:85362090\n\n
  • \nProduct Net Width:105 mm\n\n
  • \nProduct Net Height:160 mm\n\n
  • \nProduct Net Depth : 82.5 mm\n\n
  • \nProduct Net Weight:2.5 kg\n\n
  • \nPackage Level 1 Units:1 piece\n\n
  • \nPackage Level 1 Width:145 mm\n\n
  • \nPackage Level 1 Height:210 mm\n\n
  • \nPackage Level 1 Length:168 mm\n\n
  • \nPackage Level 1 Gross Weight: 2.5 kg\n\n
  • \nPackage Level 1 EAN:8015644022518\n\n
  • \nAdditional Information\n\n
  • \nCircuit Breaker Type to be Associated:Power distribution\n\n
  • \nElectrical Durability:120 cycles per hour/ 8000 cycle\n\n
  • \nMechanical Durability:Nr. Operations 240 cycles per hour\n\n
  • \nNr. Operations 25000 cycle\n\n
  • \nNumber of Poles:3\n\n
  • \nOpening Time:CB with SOR 15 ms\n\n
  • \nCB with UVR 15 ms\n\n
  • \nPower Loss:at Rated Operating Conditions per Pole 16.44 W\n\n
  • \nProduct Main Type:SACE Tmax XT\n\n
  • \nProduct Name:Moulded Case Circuit Breaker\n\n
  • \nProduct Type:CB\nRated Current (In):250 A\n\n
  • \nRated Frequency (f):50 / 60 Hz\n\n
  • \nRated Voltage (Ur):690 V\n\n
  • \nRated Impulse Withstand Voltage (Uimp):8 kV\n\n
  • \nRated Insulation Voltage (Ui):1000 V\n\n
  • \nRated Operational Voltage:690 V AC 500 V DC\n\n
  • \nRated Uninterrupted Current (Iu):250 A\n\n
  • \nRelease Type:TM\n\n
  • \nStandards:IEC\n\n
  • \nSub-type:XT4\n\n
  • \nTerminal Connection Type:Fixed Circuit-Breakers\n\n
  • \nFront Version:F\n\n
  • \nCertificates and Declarations (Document Number)\n\n
  • \nData Sheet, Technical Information:1SDC210033D0204\n\n
  • \nDeclaration of Conformity - CE:9AKK106713A5529\n\n
  • \nEnvironmental Information:1SDL000190R0001\n\n
  • \nGL Certificate:1SDL000163R0095\n\n
  • \nInstructions and Manuals:1SDH000722R0001\n\n
  • \nLR Certificate:1SDL000163R0100\n\n
  • \nClassifications\nETIM 4:EC000228 - Power circuit-breaker for trafo/generator/installation prot.\nETIM 5:EC000228 - Power circuit-breaker for trafo/generator/installation prot.\nETIM 6:EC000228 - Power circuit-breaker for trafo/generator/installation prot.\n\n
  • \nObject Classification Code:Q\n\n
  • \nUNSPSC:39120000\n\n
  • \nShipping Weight : 4 Kg\n
